Traffic Lights

Standard traffic lights that are used on Australian roads are all normally 200 mm in diameter. These need to be visible at distances of up to 300 metres.  In some circumstances a smaller traffic light with a narrower viewing angle and a lower light intensity is required. The 100 mm diameter is ideal for this application.



FOR MORE INFORMATION ON OUR PRODUCTS AND SERVICES,
NEED A QUOTE OR HAVE A QUERY
CALL US ON (07) 3205 1123 OR SUBMIT THIS FORM.

In most access control situations the two aspect red / green combination is used but some applications different formats are  required. Rotech can offer various combinations of lights including 3 aspect  red / green / amber and walk / don’t walk indicators.

All the Sentinel Traffic Lights are suitable for harsh conditions and are supplied in a waterproof ABS plastic enclosure with  adjustable mounting brackets.

The low voltage controls eliminate the need for expensive cable runs of mains power.

Ramp Controller

Traffic light ramp controllers are available for single lane access in car parks.

These PLC controlled panels control the flow of traffic by setting the traffic light sequence  depending on the direction of the vehicle flow.



For more information download our product datasheet.

adobe-PDF-iconSENTINEL TRAFFIC LIGHTS DATASHEET







SpecificationSentinel Traffic Lights
Size100mm200mm
ColourRed / GreenRed / Green
Light IntensityRed    ≥ 150cd Green ≥ 200cdRed    ≥ 400 cd Green ≥ 400cd
Temperature-4°C to 80°C-40°C to 80°C
ProtectionIP65IP55
Voltage24vdc24vdc
Housing MaterialPolycarbonatePolycarbonate
Life Span≥ 80 000 hrs≥ 70 000 hrs
Weight2.1kg6 kg
Viewing Angle30°45°



For more information download our product datasheet.

adobe-PDF-iconSENTINEL TRAFFIC LIGHTS DATASHEET
